Largest control panel ever built by Fancom

Largest control panel ever built by Fancom

In the past quarter, Fancom reached a special milestone: the largest control panel in our history was built. This impressive control panel was realised for the automation of a modern layer house and consists of no less than six separate cabinets. Together, they form an integrated solution for climate control, feeding, egg collection and lighting in two house sections.

Switch box - 3d design

Fully designed with smart wiring

The control panel is built entirely according to smart wiring technology. This means that the entire system is first designed digitally in 3D. Based on this design, a digital wiring list is automatically generated. Thus, the cabinet is first built virtually before it is physically assembled.

The corresponding cable sets are produced by a wire terminal and are custom-made: fitted with ferrules, sorted by order of assembly, by colour and diameter and with wiring information printed on the cables. This smart working method results in error-free, efficient production and installation.

Built-in Fancom systems in six cabinets

The control panel contains a complete Fancom automation system, divided into the following components:

  • Cabinet 1: Main distribution with power supplies (400A)
  • Cabinet 2: Climate and feeding system for section 1
  • Cupboard 3: Egg collection for 2 aviaries/nests + external egg collection
  • Cabinet 4: Lighting for both sections
  • Cabinet 5: Climate and feeding system for section 2
  • Cupboard 6: Egg collection for 2 aviaries/nests + external egg collection

A total of as many as 2,989 unique wires were incorporated into this project.

Switch box - Wiring

Quality and efficiency through in-house panel building team

At Fancom, all control panels are designed and built by our in-house panel building team. This team works according to the Lean Manufacturing philosophy, focusing on maximum value for the customer and eliminating waste as much as possible. With this approach, we guarantee high quality and quick, clear installation in the barn.

With this largest control panel to date, we underline our expertise in automation and innovation in the agricultural sector. An achievement we are proud of as a team!
